High Pressure Hose Crimper Hose Ferrule Crimping Tool Hydraulic Hose Making Machine

Name: High Pressure Hose Crimper Hose Ferrule Crimping Tool Hydraulic Hose Making Machine
Brand: MENSION
Price: 1 USD

Buy cheap High Pressure Hose Crimper Hose Ferrule Crimping Tool Hydraulic Hose Making Machine product

Brand Name : MENSION

Model Number : MS-E38

Certification : CE RoHS

Place of Origin : CN

MOQ : 1 Set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000 Sets Per Month

Delivery Time : 2 - 7 Working Days

Packaging Details : One Plywood For One Set

Price : Contact Us

Crimping Range : 14-87mm

Hose Size : 1/4-2inch

Die Sets : 10

Crimping Force : 640T

Max. Opening : 31mm

Color : Blue

Product Name : E38 High Pressure Hose Crimper

Application : Workshop

Power : 4KW

Size : 630*450*600mm

Weight : 200Kg

Hydraulic Oil : T46

Contact Now

HIGH PRESSURE HOSE CRIMPER MS-E38

DESCRIPTION

MS-E38 high pressure hose crimper is with human desging height, convenient to operate. With big crimping force, it can press hose up to 2 inch of high pressure and 3 inch of industrial pipes.

MAIN FEATURES

1. Advanced cylinder making technology, long life;

2. High quality mold steel, high hardness;

3. Simple panel, easy and convenient;

4. Thicken rack offering a safe plat form.

TECHNICAL DATA

Model	MS-E38 High Pressure Hose Crimper
Crimping Range	14 - 87 (mm)
Crimping Force	640 (T)
Hose Size	1/4 - 2 (inch) 4SH
Max. Opening	31 (mm)
Die Sets	10
Die Set Type	38
System Pressure	31.5 (Mpa)
Accuracy	0.01 (mm)
Control	MS
Standard Voltage	220 (V) / 380 (V)
Motor Power	4 (KW)
Length	630 (mm)
Width	450 (mm)
Height	600 (mm)
Weight	200 (KG)
Hydraulic Oil	50 (L)

High Pressure Hose Crimper Hose Ferrule Crimping Tool Hydraulic Hose Making Machine

38 CRIMPER DIE SETS

Die No.	Crimping Range	Length
6*	6 - 8mm	35
8*	8 - 10mm	35
10*	10 - 12mm	35
12*	12 - 14mm	35
14	14 - 16mm	60
16	16 - 20mm	60
20	20 - 22mm	60
22	22 - 26mm	60
26	26 - 30mm	70
30	30 - 38mm	70
38	38 - 46mm	70
46	46 - 54mm	80
54	54 - 64mm	80
64	64 - 69mm	80
69*	69 - 76mm	100

NOTE

1) Customized die sets are available with different size or shape;

2) Special voltage such as 110V, 208V, 240V, 415V (60HZ) are availbale;

3) Foot pedal is available to make the hands free;

3) * for non standard die sets.

High Pressure Hose Crimper Hose Ferrule Crimping Tool Hydraulic Hose Making Machine
